Application | Power Distribution |
Construction | Modular |
Type | Indoor Metal Clad |
Max. Rated Current | 1250a, 26.3Ka, 1600a, 40Ka |
Rated Operational Voltage | 12Kv |
Rated Insulation Voltage | 28Kvrms/75Kvpk |
Ambient temperature | 50 Degree c |
Type Test Performed at Cpri | 65.75Ka peak & 26.3Ka rms for 3Sec 100Ka peak & 40Ka rms for 3Sec |
